Aluminium Tubes 6082
Product Details:
- Shape Rectangular
- Click to View more
Aluminium Tubes 6082 Price And Quantity
- 1 Piece
Aluminium Tubes 6082 Product Specifications
- Rectangular
Aluminium Tubes 6082 Trade Information
- 1 Piece Per Day
- 2 Days
Product Description
Applications :- Highly stressed applications
- Trusses
- Bridges
- Cranes
- Transport applications
- Ore skips
- barrels
- Milk churns
Specifications :
- ASTM B221, AMS 4156, AMS QQ-A-200/9
Available Shapes :
- Round, rectangular square.
- Tempers: T6 ,0, T651, T4
Chemical Composition :
| Chemical Element | % Present |
| Manganese (Mn) | 0.40 - 1.00 |
| Iron (Fe) | 0.0 - 0.50 |
| Magnesium (Mg) | 0.60 - 1.20 |
| Silicon (Si) | 0.70 - 1.30 |
| Copper (Cu) | 0.0 - 0.10 |
| Zinc (Zn) | 0.0 - 0.20 |
| Titanium (Ti) | 0.0 - 0.10 |
| Chromium (Cr) | 0.0 - 0.25 |
| Other (Each) | 0.0 - 0.05 |
| Others (Total) | 0.0 - 0.15 |
| Aluminium (Al) | Balance |
Properties :
| Physical Property | Value |
| Density | 2.70 g/cm |
| Melting Point | 555oC |
| Thermal Expansion | 24 x10^-6 /K |
| Modulus of Elasticity | 70 GPa |
| Thermal Conductivity | 180 W/m.K |
| Electrical Resistivity | 0.038 x10^-6 .m |
| Mechanical Property | Value |
| Proof Stress | 290 Typical MPa |
| Tensile Strength | 340 Typical MPa |
| Hardness Vickers | 95 Typical HV |
| Elongation A | 6 Min % |
Alloy Designations :
Aluminium alloy 6082 also corresponds to the following standard designations and specifications but may not be a direct equivalent:
- AA6082
- HE30
- DIN 3.2315
- EN AW-6082
- ISO: Al Si1MgMn
- A96082
Supplied Forms :
Alloy 6082 is typically supplied as Channel, Angle, Tee, Square bar, Square box section, Rectangular box section, Flat bar, Tube and Sheet
- Extrusions
- Bar
- Plate
- Sheet
- Tube
